Details
When the trail beckons you to traverse above tree line and into unmarked territory, the Joplin is ready to take you there. With its 120mm of VPP™ travel and 29-inch wheels, it’s the ultimate climbing partner to help you reach any summit. And when it’s time to point downhill, its head tube angle and slack geo will navigate the most rocky terrain. Whether you’re out on a solo adventure or a soul-lifting ride with friends, the Joplin will let you soar to new heights.
X-Small | Small | Medium | |
---|---|---|---|
Reach | hi/lo(mm) | 405/403 | 430/428 | 455/453 |
Stack | hi/lo(mm) | 601/603 | 610/612 | 619/621 |
Head Tube Angle | hi/lo | 65.7/65.5 | 65.7/65.5 | 65.7/65.5 |
Seat Tube Length(mm) | 370/370 | 380/380 | 405/405 |
Front Center | hi/lo(mm) | 708/708 | 737/737 | 766/766 |
BB Height | hi/lo(mm) | 335/332 | 335/332 | 335/332 |
BB Drop | hi/lo(mm) | 38/41 | 38/41 | 38/41 |
Wheelbase | hi/lo(mm) | 1138/1138 | 1167/1167 | 1199/1199 |
Rear Center | hi/lo(mm) | 430/431 | 430/431 | 433/434 |
Head Tube Length(mm) | 95/95 | 105/105 | 115/115 |
Top Tube Length | hi/lo(mm) | 555/556 | 579/580 | 602/603 |
Seat Tube Angle | hi/lo | 76/75.7 | 76.3/76 | 76.7/76.4 |
Standover Height | hi/lo(mm) | 680/676 | 693/691 | 696/693 |
X-Small | 405mm Reach |
---|---|
Small | 430mm Reach |
Medium | 455mm Reach |
Part Numbers
Option | UPC | MPN |
---|---|---|
Matte Matcha Green / X-Small | 192219348278 | 68-24278-1-798-2399 |
Matte Matcha Green / Small | 192219348292 | 68-24278-2-798-2399 |
Matte Matcha Green / Medium | 192219348315 | 68-24278-3-798-2399 |
